Mackay sits on the coastal plain of central Queensland underlain by deeply weathered granites and metasediments. These parent rocks produce residual soils with clay fractions up to 45% and plasticity indices ranging from 18 to 35. The local water table fluctuates between 3 m and 8 m depth depending on the season, which directly affects the moisture regime of the unsaturated zone. For any excavation or footing design, understanding the weathering profile is essential. We combine field inspection with laboratory testing to classify each horizon according to AS 1726. Before assigning bearing values we also run a placa de carga to verify deformation moduli in situ.
Residual soils in Mackay lose up to 60% of their shear strength when saturated. Characterisation must capture the unsaturated state to avoid overestimating bearing capacity.
Methodology and scope
Our team mobilises a track-mounted Ditch Witch rig with hydraulic sampling tools adapted for stiff lateritic crusts common in Mackay. We extract undisturbed block samples from test pits between 1.5 m and 4.5 m depth using wax-sealed containers. The lab sequence includes moisture content, Atterberg limits, particle size distribution, and triaxial CU tests on saturated specimens. For the colluvial layers we also perform ensayo Proctor to establish compaction curves. The program covers:
Field identification – colour, structure, consistency per AS 1726
Index tests – liquid limit, plastic limit, linear shrinkage
Strength tests – unconsolidated undrained triaxial, direct shear
Chemical analysis – pH, sulphate, chloride for aggressive environment assessment
Technical reference image — Mackay
Local considerations
AS 4678 requires that earth retaining structures account for post-construction softening of residual profiles. In Mackay, the risk is twofold: loss of suction during heavy rainfall events and collapse of metastable fabric under vibration. We have documented cases where open excavations failed after 150 mm of rain in 24 hours because the apparent cohesion dropped from 30 kPa to below 5 kPa. Our characterisation protocol includes suction measurement with filter paper and collapse potential tests on undisturbed specimens. That data feeds directly into the stability analysis and drainage design. Ignoring the unsaturated behaviour leads to under-designed walls and unexpected settlements.
Test pits dug with a backhoe to depths of 4.5 m, block sampling for undisturbed fabric, Shelby tube sampling in softer zones, and in-situ vane shear for quick strength profiles. Logged per AS 1726.
02
Laboratory Classification & Strength Testing
Index tests (LL, PL, LS, grain size), direct shear, triaxial CU/UU, consolidation, and collapse potential. Results reported with design recommendations for bearing capacity and slope stability.
Applicable standards
AS 1726 – Geotechnical site investigation, AS 4678 – Earth retaining structures, AS 1289.3.1.1 – Atterberg limits, AS 1289.6.4.1 – Unconsolidated undrained triaxial
Frequently asked questions
Why is residual soil characterisation different in Mackay compared to transported soils?
Residual soils retain the relict fabric of the parent rock, so strength and stiffness vary with depth and degree of weathering. In Mackay, the clay fraction increases downward while the sand skeleton disappears, creating a highly anisotropic profile that standard borehole methods can misinterpret. Laboratory testing on undisturbed block samples is essential.
What is the typical cost range for a residual soil characterisation study in Mackay?
The cost depends on the number of test pits, the laboratory suite, and the site accessibility. For a standard residential lot with 2 pits and full lab classification, expect between AU$1,320 and AU$4,710. Complex profiles with deep saprolite or expansive clays push toward the upper end.
How do you account for the unsaturated condition of residual soils in your analysis?
We measure matric suction using the filter paper method (AS 1289.2.2.1) on intact specimens and construct the soil-water characteristic curve. Shear strength under unsaturated conditions is then estimated using the Fredlund model. This avoids the common error of assuming fully saturated strength parameters for a profile that is partly dry most of the year.
